HYBRID SOLAR ENERGY, SOLAR PANELS

Hybrid Solar Panel HB 600

Name: Hybrid Solar Panel HB 600
SKU: 2941
Price: 699.33 EUR
Availability: InStock

699,33 € VAT included

Solar panel that provides electricity (191.36 W/m2) and hot water (341.36 W/m2). With 60 high-power cells. PVT-1: first generation hybrid solar panel.

*Warranty: 12 years. Useful life: 25 years.

* Conforms to standards:

FACTORY:

· ISO 9001: Quality Management Certification.

· ISO 14001: Environmental Management Certification.

· OHSAS 18001: Occupational Health and Safety Management Certification.

PHOTOVOLTAIC:

· IEC/EN 61215: Design qualification and type approval of photovoltaic modules for terrestrial use.

· IEC/EN 61730: Safety qualification of photovoltaic modules.

THERMAL:

· SOLAR KEYMARK: Quality certification for solar thermal energy products in Europe.

SKU: N/A Categories: HYBRID SOLAR ENERGY, SOLAR PANELS Tag: featured

* The Hybrid Solar Panel, a hybrid technology that combines a mono-crystalline photovoltaic module and a high efficiency solar thermal collector.

* Simple, low-cost and low-maintenance energy solution, capable of facilitating the 0 Carbon strategy.

* The cooling produced by the water circuit improves photovoltaic performance, improving its efficiency by up to 17% compared to a traditional photovoltaic panel.

Different applications of a Hybrid Solar Panel:

– Domestic and/or commercial hot water

– Heat pump and/or heating

– Swimming pools and/or Jacuzzis

Higher output efficiency at lower temperatures than equivalent mono-crystalline PV systems.

Space saving, since only this plate is required to produce heat and electricity.

At the junction of the photovoltaic laminate and the thermal collector, a rear cover is incorporated whose function is to conserve heat, thus preventing it from being lost through the back of the panel. This means that the photovoltaic laminate is not as hot, thus enhancing the electrical part of the panel, a great advantage of a Hybrid Solar Panel.

Weight	18,5 kg
Dimensions	164 × 99 × 3 cm

Technical Specifications

Maximum working pressure: 6 bar
Application class: Class A
Hydraulic connections: 1/2”
Electrical connections: TÜV 1 x 4.0 mm²
Volumetric flow rate: 0.078 l/s
Volumetric capacity: 1.6 L
Hot water (with a temperature increase of 35ºC): 60 L – 100 L / day
Warranty: 12 years
Service life: 25 years

Plate components (exterior to interior):

Tempered glass
Mono-crystalline photovoltaic module
EVA
Heat-conducting alloy plate
Heat exchange tube in stainless steel 304
High-temperature insulation layer
Insulation
Aluminum frame

Model	Weight	Dimensions	Average thermal power*	Peak thermal power**	Gross area (Asol) (m²)	η0,b	a1 (W/m²·K)	a2 (W/m²·K²)	Aperture area (Aa) (m²)	η0,b	a1 (W/m²·K)	a2 (W/m²·K²)
HB 600	38.5 kg	2172 × 1303 × 35 mm	1065 W	1597 W	2.83 m²	0.381	4.491	0.082	2.69 m²	0.395	4.720	0.086

Model	Electrical power	Number of cells	Cell type	Current at Pmax (Imp)	Voltage at Pmax (Vmp)	Short-circuit current (Isc)	Open-circuit voltage (Voc)	Efficiency	Operating temperature	Maximum system voltage
HB 600	600 W (0/+3%)	120 (6 × 20)	Monocrystalline PERC	17.44 A	34.40 V	18.52 A	41.50 V	21.20%	-40°C ~ +85°C	1500 VDC (IEC)

Model	Series fuse rating	Power tolerance	Temperature coefficient (Pmax)	Temperature coefficient (Voc)	Temperature coefficient (Isc)	TONC
HB 600	30 A	0 ~ +3%	-0.35% / °C	-0.29% / °C	+0.048% / °C	15 ± 2 °C

Performance Studies

In a photovoltaic cell, 10% of the solar irradiation is reflected and cannot be used.

The remaining 17% of the 90% of the irradiation is absorbed by the photovoltaic cell and can be converted into electricity.

73% is converted into thermal energy.

In a photovoltaic module, the thermal output is not used. It increases the cell temperature, thus having a negative effect on the electrical efficiency of the PV module.

In standard silicon PV cells, an increase in cell temperature results in a reduction in open circuit voltage and a less pronounced increase in short circuit current.

This results in reduced electrical efficiency at the point of maximum power.

The hybrid solar panel solves the weakness of conventional photovoltaic module, extracts heat and increases the electrical efficiency of photovoltaic cells, produces solar electricity and hot water together.

The temperature difference between the hybrid solar panel and the photovoltaic modules reaches a maximum of 22ºC.

At that point, the hybrid solar panel achieves 17% more electrical energy production per m2 than the standard photovoltaic system.

Integrated throughout the entire day, the difference between the electrical yields of this and the conventional module amounts to 8.2%.

Performance analysis with 100 hybrid plates:

12 Tn/day of domestic hot water.
Capacity: 27.5 KW/hour.
Annual electricity generation: 32400 KWh (according to the effective annual sunlight in the area where the project was carried out).
Annual heat generation: 90700 KWh.
Amortization: the full initial investment is recovered in approximately 3 years.

Considerations

The maximum recommended number of modules in line to guarantee the correct filling of the panels during start-up is 6 in vertical or horizontal position.

Optional accessories:

Tubería flexible

Download Installation Manual

To download the product installation manual in .pdf click here.

Download Product Sheet

To download the product sheet in .pdf click here.
